Selectable Case Color ( White / Black )
Manual Varifocal 2.8~12mm
MODEL | HD-CD720IR-24AF | HD-SD720IR-20AF | HD-MD720IR-24AF |
Image Sensor | 1/2.9" 1.0Megapixel CMOS Sensor | ||
Total Pixels | 1280(H) X 720 (V) = 921,600 Pixels | ||
H.Resolution | More than 1000 TVL | ||
Lens | High Definition Fixed Board Lens (3.6/40) mm or Manual Varifocal 2.8~12 mm | ||
IR LED | 24 | 20 | 24 |
ICR | Yes | ||
OSD Controller | No | ||
Video Output | 1-Channel BNC HD-CVI High Definition Video Output | ||
Day & Night | Auto(Filter Change)/ BY&W / Color | ||
White Balance | Auto | ||
BLC / HLC | Auto | ||
Transmission Distance | Over 500m via 75-3 coaxial cable | ||
Power | DC12V 80mA ( IR LED ON : Max 300 mA ) | ||
Temperature | -10°C ~ 60°C / Max 85% RH |
